SZQ Permanent Magnet Variable Frequency Oil Immersed Pump

This permanent magnet variable frequency oil-immersed submersible pump is designed for efficient and stable water transfer in demanding working environments. It adopts a permanent magnet motor combined with variable frequency control technology, providing high efficiency, energy saving, and extended service life.

Pump type: Oil-immersed submersible pump
Motor type: Permanent magnet motor
Control type: Variable frequency drive system
Structure: Submersible design
Energy feature: High efficiency, energy-saving operation

Before the operation, ensure the pump is fully submerged and properly installed in the working area. Connect the unit to a stable power supply with appropriate variable frequency control settings. During operation, the system will adjust performance according to load conditions to maintain efficient output.

+86-576-86327998 / +86-13175391314 13386588880@qq.com

PREV：No previous article NEXT：24V Intelligent Permanent Magnet Variable Frequency Silent Booster Pump

Specification
Any questions?

No.	Model	Rated Flow(m³/h)	Rated Head(m)	Power(kW)	Size	Voltage(V)
1	SZQ160-6-4	160	6	4	6 inches (150mm)	380
2	SZQ200-7-5.5	200	7	5.5	6 inches (150mm)	380
3	SZQ260-7-7.5	260	7	7.5	6 inches (150mm)	380
4	SZQ250-10-11	250	10	11	6 inches (150mm)	380

What products does Zhentai provide?

Zhentai provides aerators, water pumps, submersible pumps, gasoline water pumps, and vortex blowers for aquaculture, irrigation, drainage, water transfer, and water treatment applications.
Can you help us choose the right model?

Yes. Our team can recommend suitable models based on pond size, water depth, flow demand, head, voltage, working environment, and application requirements.
Do you support OEM or customized service?

Yes. We can provide OEM/ODM support, including model selection, product configuration, branding, packaging, and specification adjustment according to order requirements.
Can Zhentai provide technical support?

Yes. We provide technical guidance for product selection, installation, operation, and daily maintenance to help customers use the equipment properly.
How can I get a quotation?

Send us your required product type, quantity, destination, and working conditions. Our team will review your request and provide a suitable quotation and solution.
